Products

DIN 2502,DIN 2573,DIN 2627,DIN 2630,DIN 2631, 2633,DIN 2634,DIN 2635 FLANGE

DIN 2527
  • DIN 2527
  • DIN2576 PN 16 Flange
  • DIN 2633
  • DIN 2527 BLANK FLANGE
  • Forged ASME B16.5 600LB 24 inch SCH160 A694 F65 Weld Neck RF Carbon Steel Flange
  • DIN 2502,DIN 2573,DIN 2627,DIN 2630,DIN 2631, 2633,DIN 2634,DIN 2635 FLANGE
  • DIN 2502,DIN 2573,DIN 2627,DIN 2630,DIN 2631, 2633,DIN 2634,DIN 2635 FLANGE
  • DIN 2502,DIN 2573,DIN 2627,DIN 2630,DIN 2631, 2633,DIN 2634,DIN 2635 FLANGE
  • DIN 2502,DIN 2573,DIN 2627,DIN 2630,DIN 2631, 2633,DIN 2634,DIN 2635 FLANGE
Model No.︰-
Brand Name︰-
Country of Origin︰-
Unit Price︰US $ 200 / pc
Minimum Order︰1 pc
Share on:

 Total 12 Related Items
Prev12345Next

Product Description

{}

{}

{}

{}

{}





DIN Flange Standards:
DIN 2527 Blind flange - PN6-PN 100
DIN 2558 Oval flange, with neck threaded - PN 6
DIN 2561 Oval flange, with neck threaded - PN 10 and PN 16
DIN 2566 Threaded flange with neck - PN 10 and PN 16
DIN 2573 Welding neck flange - PN 6
DIN 2576 Flat flange for welding - PN 10
DIN 2627 Welding neck flange - PN 400
DIN 2628 Welding neck flange - PN 250
DIN 2629 Welding neck flange - PN 320
DIN 2630 Welding neck flange - PN 1 and PN 2.5
DIN 2631 Welding neck flange - PN6
DIN 2632 Welding neck flange - PN 10
DIN 2633 Welding neck flange - PN 16
DIN 2634 Welding neck flange - PN 25
DIN 2635 Welding neck flange - PN 40
DIN 2636 Welding neck flange - PN 64
DIN 2637 Welding neck flange - PN 100
DIN 2638 Welding neck flange - PN 160
DIN 2641 Lapped flange - PN 6
DIN 2642 Lapped flange - PN 10
DIN 2655 Lapped flange - PN 25
DIN 2656 Lapped flange - PN 40
DIN 2673 Lose flange and ring with neck for welding - PN 10








Product Image

DIN 2527
DIN 2527

DIN2576 PN 16 Flange
DIN2576 PN 16 Flange

DIN 2633
DIN 2633

DIN 2527 BLANK FLANGE
DIN 2527 BLANK FLANGE

Forged ASME B16.5 600LB 24 inch SCH160 A694 F65 Weld Neck RF Carbon Steel Flange
Forged ASME B16.5 600LB 24 inch SCH160 A694 F65 Weld Neck RF Carbon Steel Flange
